Air pocket filter media F5/F6/F7/F8 bag filter

The PR-Bag Filter are made in both Ultra-fiberglass fiber or synthetic media. The media is bonded to thin non-woven synthetic backing and sewn with multiple rows of expanded stitching. These medium to high efficiency filters can be used in a variety of commercial and industrial applications as well as specialty applications such as oil mist collection, fume collection and collection of heavy concentrated file airborne contaminants.

The PR-Ba

This synthetic Pocket filter is constructed with a moisture resistant, ultrasonically welded media. The synthetic media consists of strategically layered and blended melt-blown polypropylene fibers fastened to a non-shed, high density polypropylene backing. This design creates a dual-stage filtration effect with the final layer capturing the smaller particulate from the air stream. The patented ultrasonic welding process allows the filter to be manufactured without creating stich holes in the media while still providing an increased surface area. Vertical separators are incorporated into each pocket to be manufactured without creating stich holes in the media while still providing an increased surface area. Vertical separator are incorporated into each pocket to effectively channel air throughout the life of the fiter. The header is constructed of 26-gauge galvanized steel with rolled edges to provede rigid support to the filter face and allow for easier handling. The synthetic Pocket filter high efficiency filtration while maintaining low resistance to air flow.

• Ultrasonic welding technology

• Open throat design for optimum air flow

• Galvanized steel header and J-channels for filter strength

• High efficiency filtration with low resistance to air flow

• Superior dust-holding capacity

DETIALS:

CHOOSABLE

XNGK is the professional manufacturer for air filters in Shenzhen China, our main product is Pre Panel Filter, Pre Pleated Filter, Pocket Filter, V Bank Filter, HEPA Filter, ULPA Filter, High Temperature Oven HEPA Filter, Laminar Flow Hoods, Pass Box, Air Shower, Fan Filter Unit, Clean Booth for Pharmaceutical, Food processing, Micron electronics, Hospital Cleanroom, and other commercial buildings such as airport, schools, libraries, supermarket; we also offer customized OEM service for air purifier filters, new fresh air system.

We have very strict quality control system, before production, we will test all the row material especially the glass fiber material. To make sure the pressure drop, efficiency and dust holding ability is reliable. After we make the HEPA filters, we will test if the HEPA filter get leakages by MPPS 1882 standard. We promise all the HEPA filters are without leakage and good performance. The glass fiber is made by HV company, their high quality glass fiber ensure our HEPA filters are quite good quality.

Our Production Equipment
