Class 100 HEPA Filters Aluminum Separator for Commercial HVAC System

Introduction

The filter efficiency is 99.99% @ 0.3um, Class 100 cleanliness level;

that can be used in clean bench, FFU and other air purify equipments;

Also can be used in cleanrooms of pharmaceutical, food factories, hospitals, laboratories

and so on;

Specifications:

frame: aluminum alloy, galvanized steel, alu board, sus stainless steel, plywood and so on;

filter media: fine glassfibre;

efficiency: H10-H14 EN:1822 and medium efficiency F6-F9 also available;

construction: mini pleated or deep pleated;

temperature: 80℃

temperature can reach to 200 - 400 ℃ for high temp HEPA filters;

humidity: 80% or 100%;

final pressure drop: 600Pa;

separator: hot melt or aluminum foil corrugated;

The aluminum foil separator can be used in moist environments,

high temp, strong acid and alkali situations;

the HEPA filter with aluminum separator is the most stable performance filter,

also be call as absolute HEPA filters.

XNGK is the professional manufacturer for air filters in Shenzhen China, our main product is Pre Panel Filter, Pre Pleated Filter, Pocket Filter, V Bank Filter, HEPA Filter, ULPA Filter, High Temperature Oven HEPA Filter, Laminar Flow Hoods, Pass Box, Air Shower, Fan Filter Unit, Clean Booth for Pharmaceutical, Food processing, Micron electronics, Hospital Cleanroom, and other commercial buildings such as airport, schools, libraries, supermarket; we also offer customized OEM service for air purifier filters, new fresh air system.

We have very strict quality control system, before production, we will test all the row material especially the glass fiber material. To make sure the pressure drop, efficiency and dust holding ability is reliable. After we make the HEPA filters, we will test if the HEPA filter get leakages by MPPS 1882 standard. We promise all the HEPA filters are without leakage and good performance. The glass fiber is made by HV company, their high quality glass fiber ensure our HEPA filters are quite good quality.
