Knife Edge ULPA Filter U15 99.999% EN:1822 MPPS @0.12 um Glass Fiber Media

The knife edge ULPA filters are mainly used for liquid gel seal ceiling grid system. The liquid gel seal can make sure high level filtration air tight.

The knife edge ULPA filters consist of anodized aluminum frame, HV company glass fiber efficiency U15 99.999% or U16, U17. Polyurethane glue as the sealant be installed into 4 direction of the anodized alu frame slots. The glue connect with filter pack perfectly so normally there is no leakage. Of course we will test every ULPA filters before pack them by laser particle counter according to MPPS 1822 standard.

The knife edge ULPA filter can be size customized. Standard thickness is 70, 90, 135mm. The thickness is the full thickness of frame include knife edge.

Knife edge design ULPA filters normally applied for high strict cleanroom, for example pharmaceutical or laboratories; unclear and other industries.

Specifications:

Filter media: glass fiber HV company

Frame: aluminum alloy;

Efficiency: U15 EN:1822 99.999% MPPS @ 0.12um

Size: customized;

Faceguard: coated metal mesh;

Sealant: polyurethane;

Gasket: dove tailed neoprene;

OEM: available;

XNGK is the professional manufacturer for air filters in Shenzhen China, our main product is Pre Panel Filter, Pre Pleated Filter, Pocket Filter, V Bank Filter, HEPA Filter, ULPA Filter, High Temperature Oven HEPA Filter, Laminar Flow Hoods, Pass Box, Air Shower, Fan Filter Unit, Clean Booth for Pharmaceutical, Food processing, Micron electronics, Hospital Cleanroom, and other commercial buildings such as airport, schools, libraries, supermarket; we also offer customized OEM service for air purifier filters, new fresh air system.

We have very strict quality control system, before production, we will test all the row material especially the glass fiber material. To make sure the pressure drop, efficiency and dust holding ability is reliable. After we make the HEPA filters, we will test if the HEPA filter get leakages by MPPS 1882 standard. We promise all the HEPA filters are without leakage and good performance. The glass fiber is made by HV company, their high quality glass fiber ensure our HEPA filters are quite good quality.
