Customized Size Laminar Flow Benches for Cleanroom Application Class 100

The laminar flow benches are equipments specially applied for microelectronics, fine machinery, bio-medicine, food, sterilization and other industries that need high level of air purify. This equipment can provide high level cleanliness airflow to create a sterilized, non-dust area that can help improve the yield and increase the product quality.

The customized laminar flow benches mainly used in cleanroom, that need improve the cleanliness level, for examples, the cleanroom is class 1000, but needs class 100 work place. So the laminar flow benches become quite conveniently and useful.

The laminar flow hoods got pre filter, HEPA filters. Pre filters will filter the larger dust and hair, far and so on. The HEPA filters are 99.99% efficiency @ 0.3 um, it`s class 100 efficiency. HEPA filter was made of glass fiber material ensure large dust holding capacity and low resistance.

The airflow is accelerated by centrifugal fan at velocity of 0.45m/s pass through the work area evenly.

Features:

1. Cleanliness level: class 100 ( ISO1466-1 );
2. Unique low vibration, low noise design;
3. Airflow up and down evenly;
4. Adjustable air velocity;
5. SUS stainless steel frame or painted steel, strong construction;
6. Vertical or horizontal airflow;

Options:

1. Pressure gauge;
2. UV ultraviolet light;

XNGK is the professional manufacturer for air filters in Shenzhen China, our main product is Pre Panel Filter, Pre Pleated Filter, Pocket Filter, V Bank Filter, HEPA Filter, ULPA Filter, High Temperature Oven HEPA Filter, Laminar Flow Hoods, Pass Box, Air Shower, Fan Filter Unit, Clean Booth for Pharmaceutical, Food processing, Micron electronics, Hospital Cleanroom, and other commercial buildings such as airport, schools, libraries, supermarket; we also offer customized OEM service for air purifier filters, new fresh air system.

We have very strict quality control system, before production, we will test all the row material especially the glass fiber material. To make sure the pressure drop, efficiency and dust holding ability is reliable. After we make the HEPA filters, we will test if the HEPA filter get leakages by MPPS 1882 standard. We promise all the HEPA filters are without leakage and good performance. The glass fiber is made by HV company, their high quality glass fiber ensure our HEPA filters are quite good quality.
