Customized Size Cleanroom Laminar Flow Hoods Class 100 Stainless Steel Housing

Our laminar flow hoods can be customized for every size, for single person, double person or triple person both ok.

Stainless steel housing make the laminar flow hoods quite strong, so it can be used for quite a long time. And for some specific environment that is high acid or alkali or high moist it is also very good design.

The laminar flow hoods using HEPA filters size 1220*610*69 or 915*610*69mm mini pleated. Glass fiber efficiency H13 EN: 1822 99.99@ 0.3um, this HEPA filter can create class 100 in the work platform.

UV light and pressure gauge added, UV light can kill the bacteria to create a sterilization environment. Pressure gauge can see the pressure drop of HEPA filter, give tip for when to replace the HEPA filters.

The Applications:

The vertical airflow laminar flow hoods are quite good equipments for Lab in biotechnology research center, pharmaceutical industries, hospitals, and some microelectronics industries, or LED and so on.

The Specifications:

1. Frame: stainless steel or painted steel.
2. HEPA filter: 1220*610*69mm or 915*610*69mm or customized size, the efficiency is 99.99% @ 0.3um.
3. Work plate form: stainless steel with hole or without.
4. Size for the laminar flow hoods: customized;
5. Airflow direction: vertical or horizontal.
6. Fan: back centrifugal impeller with EBM fan made in Germany.
7. Control: LED control platform screen.

XNGK is the professional manufacturer for air filters in Shenzhen China, our main product is Pre Panel Filter, Pre Pleated Filter, Pocket Filter, V Bank Filter, HEPA Filter, ULPA Filter, High Temperature Oven HEPA Filter, Laminar Flow Hoods, Pass Box, Air Shower, Fan Filter Unit, Clean Booth for Pharmaceutical, Food processing, Micron electronics, Hospital Cleanroom, and other commercial buildings such as airport, schools, libraries, supermarket; we also offer customized OEM service for air purifier filters, new fresh air system.

We have very strict quality control system, before production, we will test all the row material especially the glass fiber material. To make sure the pressure drop, efficiency and dust holding ability is reliable. After we make the HEPA filters, we will test if the HEPA filter get leakages by MPPS 1882 standard. We promise all the HEPA filters are without leakage and good performance. The glass fiber is made by HV company, their high quality glass fiber ensure our HEPA filters are quite good quality.
