Ventilation Rigid Pleated Bag Gas Turbine Industrial v bag bank air filters

Typical application:

XN- VB series Filters are made with a series of mini-pleat bead separator media packs assembled in a
V-Bank configuration. 24” x 24” x 11-1/2” size filter contain 300 square feet of media.

Due to their 4250 m3/h capacity, FloMax filter is ideal for new installations since fewer filters are required to handle the same volume of air compared to HEPA Filters of the same size with a lower capacity. As a result, less installation space is required and installation time is significantly reduced.

Parameters & Material:

- Frame: Zinc Coated Steel
- Galvanized Stel
- Stainless steel
- Media: Wet laid microfine glass paper
- Separator: Hot-melt beads
- Sealant: Polyurethane
- Gasket: Continuous foamed seal /Neoprene
- Faceguard: No faceguard
- Gasket Location: Upstream / Downstream / Both sides.
- Frame Type: Box or Single Flange
-Max.Constant Temperature: 80℃ (170℉)
- Recommended Final Resistance: 600Pa ( 2.4” W.G)
- Flammability: UL Classified
- Relative Humidity: 100%

Advantages:

• High air flow rates, up to 2500 CFM ( 4250 m3/hr)
• Maintenance-free and easy to install.
• High dust holding capacity
• Efficiency ranges from 95% up to 99.995%@0.3 microns
• High filter surface area offers low pressure drop for energy
savings and longer life.
• Each filter includes a label noting tested efficiency,pressure
drop,rated airflow;
• Constructed with ten individual mini pleat packs secured in a
specially -designed sheet aluminum V-bank frame.
• Available in a range of cleaning efficiencies 99.99% and
99.995%@ DOP
